Description
General Controls 25 touch-sensitive, motorized faders with 1-to-1 workflow RGB Select buttons with user-assignable colors Transport control 8 user-assignable buttons for mute groups, scenes, and more All-new Fat Channel controls including 8 scribble strips, encoders, and multicolor buttons Customizable user layer 7″ color touchscreen Inputs and Outputs 32 total inputs 24 channel inputs: 16 mic, 8 mic/line 1 XLR talkback mic input with recallable XMAX Class-A preamp 2 stereo Aux inputs 10 FlexMix outputs: 6 XLR, 4 balanced TRS Unbalanced stereo (RCA) tape input and output Bluetooth 4.1 wireless tape input Stereo AES/EBU digital output 2 XLR (L/R) Main outputs XLR Main summed mono output 2 TRS monitor outputs Stereo headphone output Channels and Buses 32 input channels 24 with recallable XMAX Class-A mic preamps 8 via USB and AVB only 2 stereo Aux inputs 26 buses: 16 FlexMixes (can be designated as Aux, subgroup, or matrix mixes) 4 dedicated subgroups 4 internal effects sends Stereo Main bus 24 Filter DCAs for easily and flexibly controlling groups of channels Networking Connections 1 Ethernet control network port Dynamic, self-assigned, and manual IP address modes 1 Ethercon AVB audio network port Complete ecosystem of AVB solutions, including stageboxes and personal monitor mixers (available soon) Recording On-board 34×34 SD recorder (using Capture) 38×38 USB recording interface 55×55 AVB recording interface
